Crittall-Style Steel Look Doors

Slim black steel-look aluminium doors: single doors, French doors and doors with side panels, made to measure for your opening and fitted across the UK.

Home / Steel Look Windows, Doors and Internal Screens / Steel Look Aluminium Doors

Run of black Crittall-style aluminium doors onto a garden, seen from the living room, Shepherd's Bush
Black steel look glazed bay with French doors at the back of a London house, Uxbridge
Anthracite grey steel look French doors with side panels in a flint and brick barn, near Hassocks
Black steel look French doors with side panels and toplights in a brick extension, Twickenham

Steel look aluminium doors, made to measure

Steel look doors have the slim black frames and glazing bars of original Crittall steel doors, made in thermally broken aluminium. They do not rust, they keep the heat in like a modern door, and every set is made to the size of your opening: a single back door, French doors onto the garden, or a full screen with side panels and a fanlight.

Layouts
Single doors, French doors, side panels and fanlights
Glazing bars
DT-Edgecut 20mm or 25mm bars, exclusive to DTW, or 48mm transoms
Glass
Double or triple glazed, 24 to 36mm units
Security
Multi-point locking, tested to PAS 24
Colours
Black and anthracite grey, or any RAL colour
Backed by
10-year warranty, rated 4.9 on Google

Steel Look Door Layouts

The four layouts we make most. Double doors with side panels is the most popular: the side panels make a wide opening look like one steel screen, while you only open the doors you need.

VisualisationSingle steel look aluminium door (visualisation)
Single doorOne door, for a back door, side door or a narrow opening.
VisualisationSingle steel look aluminium door with a side panel (visualisation)
Single door with side panelOne door with a fixed glass panel beside it, on either side.
VisualisationSteel look aluminium French doors (visualisation)
French doorsA pair of doors that open from the middle, with no post between them.
VisualisationSteel look aluminium French doors with side panels (visualisation)
French doors with side panelsA pair of doors between two fixed side panels: our most popular layout.

The pictures show the layout only. The size, colour, bars, handles and whether the doors open in or out are chosen with you, and the side panels can be the same width as the doors or narrower.

DT-Edgecut, Floating Lock or 48mm Transoms

We build steel look doors three ways, and the difference is in the glass. DT-Edgecut is our own design, made only by Direct Trade Windows. Each door has one glass unit with slim bars bonded to both sides, and a spacer inside the glass lined up behind every bar, so it looks like separate panes from any angle. At 20mm, our bars are the slimmest steel look bars on the market. Our standard design uses true 48mm transoms instead.

Steel look door with a floating lock and no bars (visualisation)
Floating lock, no barsOne clear pane of glass. The lock box sits in a cut-out in the glass, so the handle floats.
DT-Edgecut steel look door with 25mm stick-on bars lining up with the lock box (visualisation)
DT-Edgecut, 25mm barsSlim 25mm stick-on bars on one glass unit, lining up flush with the ends of the lock box. Exclusive to DTW.
Steel look door with 48mm transoms (visualisation)
48mm transomsOur standard design: bolder 48mm true dividing transoms meeting the lock box, with a separate glass unit for each pane.

The floating lock

On DT-Edgecut doors the glass is cut back 66mm at handle height, and the lock box is set into the cut-out, between two bars. The handle fixes to the lock box, and the frame stays slim above and below it, so the lock looks like it floats on the glass.

DT-Edgecut 48mm transoms
Glass One unit per door A separate unit for each pane
Bars 25mm or 20mm, on both sides of the glass 48mm aluminium transoms
Inside the glass Back-to-back spacer behind each bar A spacer round each pane
Lock Lock box set into a cut-out in the glass Lock box between the transoms
The look Closest to an original Crittall door Bold, more industrial lines
Who makes it Exclusive to Direct Trade Windows Our standard design
Our jobs Shepherd's Bush, Battersea, Sevenoaks, Chesham, St Albans West Ealing, Twickenham, Bermondsey

Want no bars at all? Our floating lock door is DT-Edgecut glass without the bars: one clear pane, a slim frame and the same floating lock, like our white doors in Windsor.

Black Crittall-style aluminium French doors in a white rendered wall, Wadhurst
DT-Edgecut in WadhurstBlack DT-Edgecut French doors (RAL 9005) opening onto a stone step.
Black steel look corner bay with French doors, toplights and 48mm transoms, West Ealing
48mm transoms in West EalingA black (RAL 9005) corner bay with French doors, toplights and 48mm transoms.

Fanlights, Kick Plates & Glazing Bars

The details that make a steel look door look right for the house.

VisualisationSteel look aluminium doors with side panels and a fanlight above (visualisation)
Fanlight aboveA row of glass across the top. Doors taller than 2.2 metres always have one, so the doors themselves stay a strong, standard size.
VisualisationSteel look aluminium French doors with kick plates (visualisation)
Kick platesA deeper solid rail at the bottom of each door, which takes the knocks from feet, pets and bins.
VisualisationSteel look aluminium French doors with extra horizontal bars (visualisation)
Extra horizontal barsMore bars across each door for a 1930s look. The standard door has two.
VisualisationSteel look aluminium French doors with a grid of glazing bars (visualisation)
Grid barsVertical and horizontal bars for a Georgian or warehouse grid.

Solid lower panels

The bottom pane of a door can be a solid aluminium panel instead of glass, for privacy, for a stable-door look, or to take a cat flap.

Handles

Standard lever handles, or Art Deco handles in black, brass or Alchemy bronze.

Open in or open out

Doors can open into the room or out onto the garden, and the side panels can have a small opening vent.

Steel Look Doors We've Made

Every door on this page is one we made and fitted. These are our jobs, not catalogue photos. Some photos have been tidied up: building work around the doors has been cleared and unfinished rooms finished off. The doors themselves are untouched.

Black Crittall-style aluminium glazed screen with doors on a rear extension, Englefield Green
Englefield Green, SurreyA black (RAL 9005) gridded screen with doors across the back of the house.
Black steel look corner bay and French doors lit up at night, West Ealing
West Ealing, London W13A black (RAL 9005) corner bay and French doors with 48mm transoms, lit up at night.
Textured black Crittall-style aluminium corner screen seen from inside, Battersea
Battersea, London SW11A textured black DT-Edgecut corner screen with French doors, seen from inside.
Textured black Crittall-style aluminium screen with a sloping head seen from inside, London NW10
London NW10A textured black DT-Edgecut screen, made to follow the slope of the roof.
Black Crittall-style aluminium French doors and side panels seen from inside, Sevenoaks
Sevenoaks, KentBlack (RAL 9005) DT-Edgecut French doors and side panels, looking onto the garden.
White aluminium floating lock doors with no glazing bars, Windsor
Windsor, BerkshireWhite (RAL 9016) floating lock doors with no bars: one clear pane in each door.
DT-Edgecut steel look glazed screen with a door in a brick extension, Chesham
Chesham, BuckinghamshireA DT-Edgecut screen with a door, in a new brick extension.
Textured black DT-Edgecut steel look French doors, St Albans
St Albans, HertfordshireTextured black DT-Edgecut French doors with slim 25mm bars.

More of our work: the CABÜ by the Sea case study, our steel look arched doors and steel look windows.

Why Aluminium Instead of Steel?

Steel look aluminium doors give the same slim, black look as steel doors, but they are lighter, they cannot rust, and they keep far more heat in.

  • Warmer A thermal break inside the frame stops the cold coming through, so the doors meet today's Building Regulations, which old single-glazed steel doors cannot.
  • No rust, no painting The frames are powder coated aluminium, so they only need a wash.
  • Same look Slim frames and our DT-Edgecut bars, as slim as 20mm, give the proportions of a traditional steel door.
  • Secure Multi-point locking and shoot bolts, tested to PAS 24.

Doors for inside the house, such as a kitchen or hallway screen, are on our steel look internal doors and screens page.

Technical Specifications

From
33mm
Frame Sight-Line
outer frame

47mm
Frame Depth

1.6W/m²K
U-Value
with a 1.0 W/m²K glass unit
Up to
900mm
Door Width
per door
  • SystemAlitherm Heritage steel look doors
  • Glazing BarsDT-Edgecut 20mm or 25mm bars (exclusive to DTW), or 48mm true dividing transoms
  • GlazingDouble or triple glazed units, 24mm to 36mm
  • Door HeightUp to 2,200mm, with a fanlight above for taller openings
  • SecurityMulti-point locking and shoot bolts, tested to PAS 24
  • Weather (open out)Air class 4, water class 8A, wind class 3
  • Weather (open in)Air class 4, water class 3A, wind class 3
  • StandardsBS 6375-1, Document L compliant, Kitemark certified

Glass Options

The glass units these doors take, drawn to scale. We recommend the right one for your doors when we quote.

Swipe to see each unit →

ArgonLow-EcoatingWarm edgespacerSealant4204OutsideInside28 mm unit
Standard 4/20/4Two 4 mm panes, Low-E coated, with an argon-filled gap of 20 mm. The everyday choice for windows and doors.
ArgonLow-Ecoating6166OutsideInside28 mm unit
Thicker pane 6/16/6Both panes go up to 6 mm for extra strength on larger panes and doors, keeping the same 28 mm unit.
ArgonNoiseQuieterInterlayer0.8 mmLow-Ecoating4166.8OutsideInside26.8 mm unit
Laminated / acoustic 4/16/6.8Two 3 mm sheets bonded to a tough clear interlayer. If it breaks it holds together, and the acoustic interlayer soaks up noise from busy roads.
ArgonHeatreflectedLess heatgets inLow-Ecoating4204OutsideInside28 mm unit
Solar control 4/20/4A coating on the outer pane reflects much of the sun's heat before it gets in. For south-facing glass, roofs and extensions.
ArgonArgonLow-Ecoating4124124OutsideInside36 mm unit
Triple glazed 4/12/4/12/4Three panes, two Low-E coatings and two argon gaps for the lowest heat loss. It is the heaviest unit, so the frame has to be built to carry it.
In every unit
Warm edge spacer
The bar that holds the panes apart around the edge. It is made from a low-conducting composite instead of aluminium, so the edge of the glass stays warmer, with less heat loss and less condensation. It is filled with desiccant, which soaks up any moisture sealed inside so the unit never mists.
Sealant
The black outer seal bonds the panes and spacer into one unit, keeps the argon in and keeps moisture out.
Low-E coating
An invisible metal-oxide layer on the inside face of the glass that reflects heat back into the room.

Colours & Finishes

Steel look doors are powder coated in a matt or textured finish. Black and anthracite grey are our standard colours; any other RAL colour can be made to order and adds a few weeks to the lead time.

Popular RAL Colours

  • RAL 9005 Jet Black (matt)
  • RAL 7016 Anthracite Grey (matt)
  • Textured black
  • RAL 7021 Black Grey
  • RAL 9016 Traffic White
  • Heritage Bronze (Alchemy range, exclusive to DTW)

Heritage Bronze, from the Alchemy range, is exclusive to DTW and has no RAL equivalent. Art Deco handles come in black, brass or Alchemy bronze to match.

Gallery

Crittall-Style Door FAQs

Contact Us

What are Crittall-style doors?

Crittall-style doors are doors made to look like the original steel doors made famous by Crittall: slim black frames divided by thin glazing bars. Ours are made in thermally broken aluminium, so they keep the look but are warmer, lighter and cannot rust. They are not Crittall products; Crittall is a registered trademark of Crittall Windows Ltd.

What is DT-Edgecut?

DT-Edgecut is our own steel look door design, exclusive to Direct Trade Windows. Each door has one glass unit with slim 25mm or 20mm bars bonded to both sides and a back-to-back spacer inside the glass behind every bar, so it looks like separate panes from any angle. The glass is cut back at handle height for a floating lock, which keeps the frame slim. At 20mm, our bars are the slimmest steel look bars on the market. We can also make the same floating lock door with no bars. Our standard design uses true 48mm transoms, with a separate glass unit for each pane.

Can I have French doors with side panels?

Yes, and it is the layout we make most. A pair of French doors sits between two fixed glass side panels, so a wide opening looks like one steel screen. The side panels can match the width of the doors or be narrower, and one can have a small opening vent.

What is a kick plate on a steel look door?

A kick plate is a deeper solid rail at the bottom of each door. It takes the knocks from feet, pets and bins, and gives the door a heavier, traditional look. We fit one per door.

How tall can steel look doors be?

The doors themselves are made up to 2.2 metres tall. For a taller opening we add a fanlight, a row of glass across the top, so the doors stay a strong standard size and the whole screen still fills the opening.

What colours do steel look doors come in?

Black (RAL 9005) and anthracite grey (RAL 7016) are our standard colours, in matt or textured finishes. Any RAL colour can be made to order, and our Heritage Bronze from the Alchemy range is exclusive to DTW.

Are steel look aluminium doors secure?

Yes. They have multi-point locking and shoot bolts and are tested to the PAS 24 security standard, the same standard used for new homes.

How long do steel look doors take?

Typically 6 to 8 weeks from when you sign off the drawings, depending on the colour and design. We confirm the lead time when we quote.

Do you fit steel look doors, or supply only?

Both. We survey, make and fit the doors anywhere in the UK, or supply them only for your own builder.
